Agitation tank
A mixing tank is mainly used to mix slurry before flotation separation in the beneficiation process. It can mix chemicals and slurry completely.
Agitation Tank Pictures
Description & Technical Data
It is suitable to mix slurry with density smaller than 30 % (weight ratio) and size smaller than 1mm. V-belt of motor drives impeller to mix drug and slurry completely. This machine can increase reaction time and strengthen reaction quality of the drug.
Technical Data
| Model | Tank inner diameter(mm) | Tank inner height (mm) | Effective volume (m3) | Impeller Speed(r/min) | Impeller diameter(mm) | Motor power(kw) | Dimension (mm) | Weight(t) |
|---|---|---|---|---|---|---|---|---|
| XB-1000 | 1000 | 1000 | 0.58 | 530 | 255 | 1.5 | 1173*1138*1491 | 1.0 |
| XB-1200 | 1200 | 1200 | 1.4 | 340 | 400 | 2.2 | 1354*1310*1742 | 1.1 |
| XB-1500 | 1500 | 1500 | 2.2 | 320 | 400 | 3.0 | 1656*1572*2171 | 1.2 |
| XB-2000 | 2000 | 2000 | 5.6 | 290 | 550 | 5.5 | 2380*2162*2850 | 2.3 |
| XB-2500 | 2500 | 2500 | 11.2 | 280 | 650 | 15 | 3036*2716*3543 | 3.4 |
| XB-3000 | 3000 | 3000 | 19.1 | 210 | 700 | 18.5 | 3604*3216*4250 | 4.9 |
| XB-3550 | 3550 | 3550 | 30 | 230 | 850 | 22 | 3940*3766*5386 | 7.3 |
| XB-4500 | 4500 | 4500 | 38 | 122 | 1000 | 45 | 4720*4800*6600 | 9.7 |
Frequently Asked Questions
Q: What is the smallest gold particle size this concentrator can recover?
A: It can recover gold particles as fine as 0.004mm, with a recovery rate of approximately 97% for this size fraction.
Q: How often do I need to clean out the concentrate?
A: The cleaning-up cycle is typically 1–4 hours for vein gold and 2–6 hours for placer gold, depending on the grade of your ore.
Q: Does this machine require chemicals?
A: No. The centrifugal concentrator uses only water and electricity. It is a completely physical separation process with zero chemical pollution.
Q: Can I use this concentrator for tailings re-processing?
A: Yes. It is widely used to recover fine gold from old tailings, grinding circuit discharges, and flotation concentrates where fine gold has not been fully captured.
Why Choose Hengcheng for Your Gold Recovery Project?
With over 25 years of experience in mineral processing equipment manufacturing, we specialize in designing customized gravity separation circuits for alluvial gold, rock gold, and complex ores. Furthermore, we provide a full package of services—from engineering consultation and ore testing to on-site installation, commissioning, and personal training. Therefore, you can rely on us from the very beginning of your project to the final operation.
