Disc Vacuum Filter
This machine is a laboratory-type latest filtration equipment that can filter intermittently or continuously. It is suitable for laboratories and small factories in the fields of mineral processing, metallurgy, geology, chemical industry, building materials, petroleum, paper making, artificial crystal, etc.
Machine Details Show
Working Principle of Disc Vacuum Filter
This equipment comprises chassis, large and small filter discs, exhaust pipes, water supply pipes, electrical appliances, vacuum pumps, vacuum tanks, and other parts.
There is a filter system composed of large and small filter discs, suction pipes, vacuum tanks and vacuum gauges, which are directly connected to the negative pressure area of the vacuum pump, eliminating the need for a complete set of devices such as gas-water separation. It is directly pumped out by the vacuum pump, which improves the filtration efficiency, reduces the number of shutdowns and starts, reduces the failure, and prolongs the service life of the equipment.
Parameters
| Item | Unit | XTLZ-Ø260/200 | DL-5C |
| Filter disc diameter | mm | Big disc Ø 260 Small disc Ø 200 | Big disc Ø 240 Small disct Ø 120 |
| Filter disc capacity | L | Big disc 4.2L/Small disc 2.5L | Big disc 3.6L/Small disc 0.64L |
| Vacuum pressure | kpa | ≤91.2 | ≤91.2 |
| Pulp concentration | % | 10-30 | 10-30 |
| Pulp size | mm | ≤0.5 | ≤0.5 |
| Dry weight of filtered sample | g | Big disc<600/Small disc<150 | Big disc<500 / Small disc<100 |
| Filter time | min | 5-10 | 5-10 |
| Drainage time | s | 30 | 30 |
| Filter cake moisture | % | ≤20 | ≤20 |
| Voltage | v | 380 | 380 |
| Power | kw | 1.5 | 1.5 |
| Weight | kg | 160 | 160 |
| Dimension | mm | 710×590×1145 | 1080x530x930 |
